| Brand Name : | EQT coffee bike |
| Model Number : | Coffee scooter-20210513 |
| Certification : | CE |
| Price : | Negotiation |
| Payment Terms : | T/T, Western Union |
| Supply Ability : | 5000 Set/Sets per Month |
| Delivery Time : | 20-30 days |
| Vehicle size | Length 2070mm, width 700mm, height 1130mm~1250mm (adjustable height) | Endurance | 70km (battery 30A) |
| Wheelbase | 1350mm | Damping system | 8 spring shock absorbers on the front wheel, 2 spring shock absorbers on the rear bracket |
| Own weight | ≈60KG | Lighting system | LED turn signal, LED brake light, LED headlight |
| Rated load | 300KG | Smart dashboard | Three-speed power-assisted mode, waterproof grade IP65, USB charging |
| Hub Motor | Rear-drive hub motor power 350W*2/waterproof grade IP54 | USB charging port | 5V6A |
| Torque | Maximum torque 43N.M | Multi-function switch | Headlight switch, turn signal switch, horn switch, reverse switch |
| Gradeability | ≈15° | key | remote key |
| Maximum speed | 18KM/H | Reversing function | Equipped/waterproof grade IPX4 |
| Tire specifications | Front 11 inch (90/65-6.5) tubeless tire, rear 14 inch (14X2.50/8PR) tubeless tire | speaker | Equipped/waterproof grade IPX4 |
| Brake | Hydraulic disc brakes at the front and rear | Speed adjustment | High, medium and low three gears |
Electric scooter frame overview:
1. Battery compartment, 2. Main pedal, 3. Brake light/left turn signal, 4. Brake light/right turn signal, 5. Rear shock absorber, 6. Rear disc brake, 7. Motor wheel (14 inch vacuum tire) 8. Charging port, 9. Platform cover, 10. Height-adjustable handlebar, 11. Headlight/horn switch, 12. Multifunctional acceleration dashboard, 13. Soft handle, 14. Front brake handle, 15. Rear brake handle, 16. Front disc brake, 17.11 inch vacuum tires, 18. Front wheel shock absorption system, 19. Anti-collision bracket, 20. Headlight/horn
Power information:
| Braking distance | 1.6m(18km/h) |
| Type of battery | Li battery |
| Battery specifications | 15A/20A/30A/40A |
| Battery charging current | Standard 4A/Quick charge 5A |
| Charging time | Quick charge 6h (battery 30A) |
Package:
3CBM
Q: Are your company a trading one or a factory?
A: Factory + trade (mainly factories, so the quality can be ensured
and price competitive)
Q: How long have your company run on tricycle?
A: 8 years focusing on tricycle,8 years exporting experience.
Q: Which payment terms are you accept?
A: Payment Terms: T/T, Western Union.
Q: After an order is placed, when to deliver?
A: it will be decided by the time of the factory production and
your quantity.Normally 25 business days.
|
|
